Sold out
Merida 2026 eOne-Sixty 875
$9,499
Description
CLIMB. RIDE. REPEAT.
Our durable aluminium e-bike frame gets a removable 750 Wh battery and an optional 360 Wh extender for a huge range, all paired with our award-winning suspension and geometry plus durable, high-performance kit from RockShox and Shimano.
KEY FEATURES
- Fourth generation LITE aluminium frame with 174 mm rear wheel travel.
- Rockshox Zeb fork with 170 mm travel and Super Deluxe rear shock.
- Hardwearing Shimano XT Linkglide drivetrain and MERIDA tubeless-ready wheelset.
- User-removable 750 Wh battery with optional 360 Wh range extender, powerful Shimano EP801 drive unit.
- Mixed wheel size as standard with option to full 29″.
- Reach-based AGILOMETER sizing system with 30-230 mm adjustable dropper post.
Specifications
Motor/Drive Unit: Shimano STePS EP801
Motor Power (Watts): 250
Motor Torque (Newton-Meters): 85
Battery: Shimano BT-EN817
Battery Size (Watt-Hours): 712
E-Drive System: Mid Drive
Display: Shimano SC-EM800
SPECIFICATIONS
Frame: eONE-SIXTY LITE IV, MAT aluminium, 160mm suspension travel, 29x2.6" max. wheelsize, 148x12mm axle standard, intube, 750Wh
Fork: Rock Shox ZEB Select, Air, 170mm suspension travel, Tapered, 44mm fork offset, 29x2.8" max. wheelsize
Shock: Rock Shox Super Deluxe Select
Rear Derailleur: Shimano XT RDM8130 LinkGlide 11
Shifters: [F]: Shimano SL-MT500-IL / [R]: Shimano XT M8130 11
Brakes: Shimano XT, 4 piston
Rotors: [F]: Shimano RT64, 220mm / [R]: Shimano RTEM600, 203mm
Chain: Shimano LG500
Crank: FSA 1x Steel Chainring, 36T, Shimano FC-E8150, 165mm all sizes
Hubs: [F]: Shimano XT, 110x15mm width, 32H, Centerlock / [R]: Shimano XT, 148x12mm width, 32H, Centerlock
Rims: Reynolds 309 Enduro Comp, 30mm inner width, MAT aluminium, Tubeless ready (tubeless tape installed), front 29" / rear 27.5"
Axles: [R]: MERIDA EXPERT TR, including removable lever, 6/4mm allen key
Freewheel: Shimano LG700, 11-50T, 11-speed
Tyres: [F]: Maxxis Assegai, 29x2.5", fold, TR EXO+ 3C MaxxGrip / [R]: Maxxis Minion DHR II, 27.5x2.4", fold, 3C DD TR MaxxTerra
Spokes: Black stainless, black nipples
Handlebar Stem: MERIDA EXPERT eTR II, MAT aluminium, 35mm diameter, 0-degree stem angle, Supernova mount, 40mm all sizes
Handlebar: MERIDA EXPERT eTR, 780mm width
Grips: MERIDA EXPERT EC
Headset: Acros ICR MERIDA EXTERNAL neck w/ Blocklock
Seat Clamp: MERIDA EXPERT
Seat Post: MERIDA TEAM TR II, 34.9mm diameter, 0mm setback, XSHORT=30-200mm suspension travel / SHORT-XLONG=30-230mm suspension travel
Saddle: PROXIM ALTIUS Steel, V-mount adapter, incl. MERIDA minitool
Pedals: VP VPE-527
Lights: [F]: Lezyne Hekto StVZO E350+ Reverse; reverse MERIDA Custom Mount / [R]: LEZYNE LED FEMTO USB-C REAR STVZO
Fenders: EOF-204
Accessories: MERIDA Multitool with saddlebox
Sizes: XSHORT, SHORT, MID, LONG or XLONG
Colours: Guarded Gold (Grey)
Motor Power (Watts): 250
Motor Torque (Newton-Meters): 85
Battery: Shimano BT-EN817
Battery Size (Watt-Hours): 712
E-Drive System: Mid Drive
Display: Shimano SC-EM800
SPECIFICATIONS
Frame: eONE-SIXTY LITE IV, MAT aluminium, 160mm suspension travel, 29x2.6" max. wheelsize, 148x12mm axle standard, intube, 750Wh
Fork: Rock Shox ZEB Select, Air, 170mm suspension travel, Tapered, 44mm fork offset, 29x2.8" max. wheelsize
Shock: Rock Shox Super Deluxe Select
Rear Derailleur: Shimano XT RDM8130 LinkGlide 11
Shifters: [F]: Shimano SL-MT500-IL / [R]: Shimano XT M8130 11
Brakes: Shimano XT, 4 piston
Rotors: [F]: Shimano RT64, 220mm / [R]: Shimano RTEM600, 203mm
Chain: Shimano LG500
Crank: FSA 1x Steel Chainring, 36T, Shimano FC-E8150, 165mm all sizes
Hubs: [F]: Shimano XT, 110x15mm width, 32H, Centerlock / [R]: Shimano XT, 148x12mm width, 32H, Centerlock
Rims: Reynolds 309 Enduro Comp, 30mm inner width, MAT aluminium, Tubeless ready (tubeless tape installed), front 29" / rear 27.5"
Axles: [R]: MERIDA EXPERT TR, including removable lever, 6/4mm allen key
Freewheel: Shimano LG700, 11-50T, 11-speed
Tyres: [F]: Maxxis Assegai, 29x2.5", fold, TR EXO+ 3C MaxxGrip / [R]: Maxxis Minion DHR II, 27.5x2.4", fold, 3C DD TR MaxxTerra
Spokes: Black stainless, black nipples
Handlebar Stem: MERIDA EXPERT eTR II, MAT aluminium, 35mm diameter, 0-degree stem angle, Supernova mount, 40mm all sizes
Handlebar: MERIDA EXPERT eTR, 780mm width
Grips: MERIDA EXPERT EC
Headset: Acros ICR MERIDA EXTERNAL neck w/ Blocklock
Seat Clamp: MERIDA EXPERT
Seat Post: MERIDA TEAM TR II, 34.9mm diameter, 0mm setback, XSHORT=30-200mm suspension travel / SHORT-XLONG=30-230mm suspension travel
Saddle: PROXIM ALTIUS Steel, V-mount adapter, incl. MERIDA minitool
Pedals: VP VPE-527
Lights: [F]: Lezyne Hekto StVZO E350+ Reverse; reverse MERIDA Custom Mount / [R]: LEZYNE LED FEMTO USB-C REAR STVZO
Fenders: EOF-204
Accessories: MERIDA Multitool with saddlebox
Sizes: XSHORT, SHORT, MID, LONG or XLONG
Colours: Guarded Gold (Grey)
